Prime Mover 6x4
| Specifications | |
|---|---|
| Model | Hati Plus |
| Engine | Weichai WP10.340E32, 6 in-line, water cooling, EGR, air intercooler, turbocharged |
| Power | 250 kW (340 hp) @ 2200 rpm |
| Torque | 1350 Nm @ 1200-1600 rpm |
| Piston Displacement | 9726 cc |
| Transmission | FAST 9JSD135T (9 forward speeds + 2 reverse speeds) |
| Max. Climbing Slope | 23% |
| Clutch | 430 mm, dry type, single plate dry coil spring, diaphragm spring clutch, hydraulic controlled air added assist |
| Steering | Recirculating ball type hydraulic power steering |
| Suspension | Leaf spring, bogie type |
| Frame | Side rails, punching and riveted construction |
| Max. Loading Front Axle | 9000 kg |
| Max. Loading Rear Axle | 16000x2 kg |
| Rear Axle Ratio | 4.111 |
| Wheelbase | 3150+1350 mm |
| Max. Speed | 75 km/h |
| Cabin | 44 degrees, forward electric tilt cab |
For Price Please Call
+880 1730-781716 or +880 1730-781722
