Bahadur Truck (6x4) 23 Ton
| Specifications | |
|---|---|
| Model | Bahadur 23 Ton |
| Engine | Weichai WP6.240E32, 6 in-line, water cooling, EGR, air intercooler, turbocharged |
| Power | 178 kW (240 hp) @ 2300 rpm |
| Torque | 800 Nm @ 1400-1600 rpm |
| Piston Displacement | 6750 cc |
| Transmission | FAST 8JS10ST (8 forward speeds + 2 reverse speeds) |
| Max. Climbing Slope | 28% |
| Clutch | 395 mm, dry type, single plate dry coil spring, diaphragm spring clutch, hydraulic controlled air added power operating |
| Steering | Integrated power steering |
| Suspension | Leaf spring |
| Frame | Side rails, punching and riveted construction |
| Max. Loading Front Axle | 6500 kg |
| Max. Loading Rear Axle | 13000*2 kg |
| Rear Axle Ratio | 5.833 |
| Wheelbase | 4615 + 1350 mm |
| Max. Speed | 75 km/h |
| Cabin | 44 degrees, integrated front tiltable |
| Front Wheel Track | 2020 mm |
| Rear Wheel Track | 1860 mm |
| Overall Dimension | Length 10975 x Width 2500 x Height 2830 mm |
| Curb Weight | 5860 kg |
| Tires | 10.00 R20, (6+1) |
| Brake System | Dual circuit, air pressure brake |
| Payload | 11050 kg |
| Gross Vehicle Weight | 16000 kg |
| Ground Clearance | 255 mm |
| Battery | (2 x 12) 24 Volts, 150 Ah |
| Fuel Tank | 400 liters |
| Driving | 6x4 |
| Condition | Made for Bangladesh's weather and roads, capable of carrying sand, soil, stone, coal. |
- Spacious driving space, luxurious truck interior.
- Dual cup holder design.
- Large glove compartment.
- Double layer a wider truck sleeper.
- Adjustable steering wheel
- Delivery on both cash and hire purchase.
- For hire purchase, minimum down payment is 30%.
- Registration & Insurance are free of charge.
- Installment period maximum up to 36 months.
- 6 times free services.
- For covered van body making charge is applicable.
